EL5205ISZ-T7

high speed voltage feedback amplifier, 13.2V, 80mA, 700MHz, SOIC-8

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.50~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.50~1.00

PartNumber:: EL5205ISZ-T7

Brand:: Elantec Semiconductor - Intersil | Pack: SO | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Susana's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-05-10

From Other Seller

Part Number:EL5205ISZ-T7
US $0.50 - 1.00
ECA1HHG220

US $2.00 - 10.00 / Piece
(0) Remove
LM64P101

US $240.00 - 300.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The EL5205ISZ-T7 is a high speed voltage feedback amplifier based on the current feedback amplifier architecture. This gives the typical high slew rate benefits of a CFA family along with the stability and ease of use associated with the VFA type architecture. This family is available in single, dual, and triple versions, with 200MHz, 400MHz, and 700MHz versions. The EL5205ISZ-T7 operates on single 5V or ±5V supplies from minimum supply current. The EL5205ISZ-T7 also features an output enable function, which can be used to put the output in to a high-impedance mode. This enables the outputs of multiple amplifiers to be tied together for use in multiplexing applications.

Parametrics

EL5205ISZ-T7 absolute maximum ratings: (1)Supply Voltage between VS+ and GND: 13.2V; (2)Input Voltage: ±VS; (3)Differential Input Voltage: ±4V; (4)Maximum Output Current: 80mA; (5)VS+ to VS- Maximum Slew Rate: 1V/μs; (6)Storage Temperature Range: -65℃ to +150℃; (7)Ambient Operating Temperature Range: -40℃ to +85℃; (8)Operating Junction Temperature: 150℃.

Features

EL5205ISZ-T7 features: (1)Specified for 5V or ±5V applications; (2)Power-down to 17μA; (3)-3dB bandwidth = 700MHz; (4)±0.1dB bandwidth = 45MHz; (5)Low supply current = 9.5mA; (6)Slew rate = 7000V/μs; (7)Low offset voltage = 10mV max; (8)Output current = 160mA; (9)AVOL = 1400; (10)Diff gain/phase = 0.01%/0.02°; (11)Pb-free plus anneal available (RoHS compliant).
