Product Summary

The SN74HC32DR is a quadruple 2-input positive-or gate. It contains four independent 2-input OR gates.

Parametrics

SN74HC32DR absoltue maximum ratings: (1)Supply voltage range, VCC: –0.5 V to 7 V; (2)Input clamp current, IIK: ±20 mA; (3)Output clamp current, IOK: ±20 mA; (4)Continuous output current, IO: ±25 mA; (5)Continuous current through VCC or GND: ±50 mA; (6)Package thermal impedance, θJA: 96℃/W; (7)Storage temperature range, Tstg:–65 to 150℃.

Features

SN74HC32DR features: (1)Wide Operating Voltage Range of 2 V to 6 V; (2)Outputs Can Drive Up To 10 LSTTL Loads; (3)Low Power Consumption, 20-μA Max ICC; (4)Typical tpd = 8 ns; (5)±4-mA Output Drive at 5 V; (6)Low Input Current of 1 μA Max.

Diagrams

SN74HC32DR block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
SN74HC32DR
SN74HC32DR
Texas Instruments
Gates (AND / NAND / OR / NOR) Quad 2-Input
Data Sheet
0-1: $0.20
1-25: $0.16
25-100: $0.12
100-250: $0.08
SN74HC32DRE4
SN74HC32DRE4
Texas Instruments
Gates (AND / NAND / OR / NOR) Quadruple 2-Input Positive-OR Gates
Data Sheet
0-1: $0.23
1-25: $0.19
25-100: $0.14
100-250: $0.09
SN74HC32DRG4
SN74HC32DRG4
Texas Instruments
Gates (AND / NAND / OR / NOR) Quadruple 2-Input Positive-OR Gates
Data Sheet
0-1: $0.23
1-25: $0.19
25-100: $0.14
100-250: $0.09
