FM25L16BGTR

16Kb FRAM Serial 3V Memory, Sophisticated Write Protection Scheme, Low Power Consumption, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~5.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~5.00

PartNumber:: FM25L16BGTR

Brand:: Ramtron International Corporation - RIC | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Susana's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-11-29

From Other Seller

Part Number:FM25L16BGTR
US $1.00 - 5.00
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
HEF4093BT

US $0.15 - 1.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The FM25L16BGTR is a 16-kilobit nonvolatile memory employing an advanced ferroelectric process. A ferroelectric random access memory or FRAM is nonvolatile and performs reads and writes like a RAM. The FM25L16BGTR provides reliable data retention for 45 years while eliminating the complexities, overhead, and system level reliability problems caused by EEPROM and other nonvolatile memories. Unlike serial EEPROMs, the FM25L16BGTR performs write operations at bus speed. No write delays are incurred.

Parametrics

FM25L16BGTR absolute maximum ratings: (1)Power Supply Voltage with respect to VSS:-1.0V to +5.0V; (2)Voltage on any pin with respect to VSS:-1.0V to +5.0V and VIN < VDD+1.0V; (3)Storage Temperature:-55℃ to + 125℃; (4)Lead Temperature (Soldering, 10 seconds):300℃; (5)Electrostatic Discharge Voltage:Human Body Model (JEDEC Std JESD22-A114-B):4kV, Charged Device Model (JEDEC Std JESD22-C101-A):1kV; (6)Package Moisture Sensitivity Level:MSL-1.

Features

FM25L16BGTR features: (1)Organized as 2,048 x 8 bits; (2)Unlimited Read/Write Cycles; (3)45 Year Data Retention; (4)NoDelay Writes; (5)Advanced High-Reliability Ferroelectric Process; (6)Up to 18 MHz Frequency; (7)Direct Hardware Replacement for EEPROM; (8)SPI Mode 0 & 3 (CPOL, CPHA=0,0 & 1,1); (9)Hardware Protection; (10)Software Protection; (11)Low Voltage Operation 2.7 to 3.6V; (12)1 μA Standby Current; (13)Industrial Temperature -40℃ to +85℃; (14)“Green”/RoHS 8-pin SOIC Package; (15)“Green”/RoHS 8-pin TDFN Package; (16)TDFN Footprint Conforms to TSSOP-8.
